CELLMAX-O-CPUSE Cell-Max™ Omni In-building Antenna, 698–960
Cell-Max™ Omni In-building Antenna, 698–960 MHz and 1710–2700 MHz
Product Classification
| Product Type | In-building antenna |
| Product Brand | Cell-Max™ |
General Specifications
| Application | Indoor |
| Antenna Type | Omni |
| Antenna Array Characteristic | SISO |
| Polarization | Vertical |
| Color | White |
| Mounting | Thru-hole ceiling mount (optional) |
| Number of Ports | 1 |
| Pigtail Cable | KSR195, plenum rated |
| Radome Material | ABS |
| RF Connector Interface | N Female |
Dimensions
| Height | 85 mm | 3.346 in |
| Pigtail Length | 315 mm | 12.402 in |
| Outer Diameter | 186 mm | 7.323 in |
Electrical Specifications
| Impedance | 50 ohm |
| Operating Frequency Band | 698 – 960 MHz | 1710 – 2700 MHz |
Electrical Specifications
| Frequency Band, MHz | 698–800 | 800–960 | 1710–2700 |
| Gain, dBi | 2.0 | 2.0 | 5.0 |
| Beamwidth, Horizontal, degrees | 360 | 360 | 360 |
| VSWR | Return loss, dB | 1.8 | 10.9 | 1.5 | 14.0 | 1.5 | 14.0 |
| Input Power per Port, maximum, watts | 50 | 50 | 50 |
Environmental Specifications
| Operating Temperature | -40 °C to +60 °C (-40 °F to +140 °F) |
| Relative Humidity | Up to 100% |
Packaging and Weights
| Height, packed | 135 mm | 5.315 in |
| Width, packed | 195 mm | 7.677 in |
| Length, packed | 195 mm | 7.677 in |
| Packaging quantity | 1 |
| Weight, gross | 0.4 kg | 0.882 lb |
| Weight, net | 0.3 kg | 0.661 lb |
